Falcon Energy 51.2V 16.1kWh Battery System

A fully assembled, commercial-grade energy storage solution designed for residential and light commercial installations. Built for reliability, performance and seamless inverter integration, this is a robust, no-nonsense battery system ready to deploy straight out of the box.

Engineered using high-quality 3.2V 314Ah LiFePO4 cells in a 1P16S configuration, and managed by a powerful 200A BMS with active balancing, this system delivers stable performance, strong discharge capability and long-term reliability.

Designed with installers in mind, the Falcon system is simple to integrate, easy to scale and built to perform in demanding environments.

Key Features

Fully Assembled
Delivered ready to install, reducing on-site time and simplifying commissioning.

Commercial Grade Build
Built using 16 x 314Ah LiFePO4 Grade A cells for consistent, reliable performance.

High Power Output
Capable of up to 200A discharge, ideal for whole-home and high-load applications.

Scalable System
Supports parallel connection of up to 15 units, enabling large-scale storage systems.

Reliable Performance
Engineered for stability with low internal resistance and consistent output under load.

Long Lifespan
Designed for thousands of cycles with high capacity retention over time.

Seamless Integration
Compatible with leading inverter brands via CAN and RS485 communication.

Smart Connectivity
Integrated communication ports allow clean system integration and monitoring.

Advanced Cell Management
200A BMS with integrated protections and active balancing for optimal cell health.

Built-In Protection
Comprehensive safety features including overcharge, over-discharge, temperature and short circuit protection.

Installer Friendly
Simple wiring, clear terminal layout and straightforward commissioning process.

Technical Specifications

• Model: FE-PB1-JK314
• Rated Energy: 16.1kWh
• Nominal Voltage: 51.2V
• Capacity: 314Ah
• Configuration: 1P16S
• Operating Voltage Range: 44V – 55V
• Charge Voltage: 58.4V
• Max Charge Current: 140A
• Max Discharge Current: 200A
• Cycle Life: 6000+ cycles to ≥80% capacity
• Operating Temperature:
  • Charge: 0°C to 50°C
  • Discharge: -20°C to 55°C
• Communication: CAN, RS485, RS232
• BMS: 200A intelligent BMS with active balancing
• Weight: ~118kg

What’s Included

• Pre-assembled battery unit
• Integrated BMS and protection systems
• Communication ports for inverter integration
• Internal cabling and busbars pre-installed

Installation Notes

Always connect all negative conductors before attaching the positive.

For higher power systems or parallel installations, external busbars may be required to manage current safely and efficiently.
